Customized IP Testing Equipment IEC 60529 Dripbox Adjustable Drop Height

Brand Name : KingPo
Certification : Calibration Certificate
Place of Origin : China
MOQ : 1
Price : To be quoted
Payment Terms : T/T
Packaging Details : Satety plastic tool box or plywood package
Drops of water tank size : length (1100mm) x width (800mm) × height (350mm)
Water tank ballast weight : up to 150 kg
Drop height : 200mm ~ 2000mm adjustable
Dripping speed : 1+0.5mm / min ~ 3+0.5mm / min
Chassis to withstand the weight : ≤ 100kg
Columns bear a weight : ≤ 50kg
Contact Now

IEC 60529 Drip Box, IPX1/IPX2


IPX1, IPX2, IEC60529, GB4208, vertical drop test box.


IPX1 uses the vertical drop of water tank, shell in the speed of 1r/min turntable, turntable axis and the specimen axis distance eccentricity is about 100mm, the water flow is 1mm/min, duration of 10 minutes.

IPX2 uses the vertical drop of water tank, shell four fixed positions in the tilted 15 degrees, table does not turn, the water flow of 3mm/min, each inclined position for 2.5 minutes.

Drops of water tank size length (1100mm) x width (800mm) × height (350mm)

Can be customized according to customer requirements.

Water tank ballast weight up to 150 kg

Drop height 200mm ~ 2000mm adjustable

Dripping speed of 1+0.5mm / min ~ 3+0.5mm / min

The test time of 0.01S ~ 99h99min.

Diameter of rotary table? 600mm (can be customized according to customer requirements)

Rotary speed of about 1 rpm

The turntable angle horizontal or inclined angle of 15 degrees.

Chassis to withstand the weight of ≤ 100kg

Columns bear the weight of ≤ 50kg

Drops of water tank made of stainless steel materials,

Drop height can be achieved by automatic lifting mechanism

Power supply for AC220V / 50Hz
